XY3100E


XY3100E is a high-performance, highly integrated SoC chip designed for NB-IoT, BLE,and GNSS scenarios.

This chip is fully compatible with the 3GPP R13/R14 protocols and the lowpower Bluetooth 5.1 protocol, offering a low-power, cost-effective solution for IoT applications, such as smart city, intelligent transportation, asset tracking, logistics tracking, remote healthcare etc.

Product Advantage

    • b4_icon01.svg

      NB-IoT highly integrated

      Integrated PA, filter, Switch, etc.

    • b4_icon01.svg

      NB-IoT ultra-low power and ultra-high performance

      DeepSleep:2.5uA;TX 250mA@23dB; RX 20mA

      support ultra-wide voltage : 2.2-4.5V

      sensitivity : simplix communication -118dBm

    • b4icon02-193.svg

      GNSS ultra-low power and ultra-high performance

      GNSS acquisition power consumption: 42mW

      GNSS tracking power consumption: 39mW

      GNSS backup power consumption: 5uA

      Cold start sensitivity -148dBm

      Hot start sensitivity -155dBm

      Re-capture sensitivity -156dBm

      Sensitivity tracking -161dBm

    • b4icon02-193.svg

      BLE ultra-low power and ultra-high performance

      TX power 0dBm(typical), 8dBm(Max)

      RX -96dBm @ BLE 1Mbps -94dBm @ BLE 2Mbps

      30mA BLE TX@0dBm@1Mbps

      22mA BLE RX@0dBm@1Mbps

Basic Parameter

    • Communication protocol

      R13, R14, R15

    • Processor

      ARM Cortex - M3; 32K~92Mhz

    • Encapsulation

      7mm*8.5mm QFN78

    • Frequency band

      Bands 1/3/4/5/8/12/20/28/71

    • Hardware peripheral

      UART/CSP/GPIO /ADC/I2C/SPI/ QSPI etc.

    • Operating temperature

      -40°C to +85°C
