XY4100LC


The XY4100LC is a cost-effective Cat.1 bis SoC with a high-performance RISC-V processor.

It integrates  modem, PMU, pSRAM, and Flash, ideal for compact LTE single-mode modules for data transmission and OpenCPU applications.

It has various interfaces, supporting USB, UART, SPI, I2C, ADC, PWM, USIM and CAN compatible interfaces, ensuring excellent expandability.

Product Advantage

    • b4_icon01.svg

      High performance processor

      High-performance RISC-V 64bit processor

      XY4100A: Flash 8MB；PSRAM 8MB

      XY4100LC: Flash 4MB；PSRAM 4MB

      Support external QSPI flash

    • b4_icon01.svg

      High integration, rich interface resources

      Integrate BB, PMIC, Flash, PSRAM

      Integrate LCD controller

      Integrate Camera controller

      Support USB2.0, UART, SPI, I2C, ADC, PWM, etc.

      Support CAN compatible interface for two wheelers, BMS

    • b4icon02-193.svg

      Low power consumption

      Support PSM, eDRX

      Power down: 4uA

      Sleep: 2mA

    • b4icon02-193.svg

      Software characteristics

      OpenCPU

      IPV4, IPV6 and non-IP，UDP, TLS/DTLS

      MQTT(s), FTP(s), DHCP V4/V6, HTTP(s), DNS, NDP, CoAP，SLAAC, SNTP，LWM2M

      RNDIS, ECM，PPP

      FOTA

Basic Parameter

    • Communication protocol

      R13

    • Processor

      RISC-V 64bit

    • Encapsulation

      BGA 6.4mm*7.2mm

    • Frequency band

      FDD B1/2/3/4/5/7/8/12/20/28
      TDD B34/B38/B39/B40/B41

    • Hardware peripheral

      USB/UART/LCD-SPI/Camera-SPI/I2C/ADC/PWM/CAN compatible

    • Operating temperature

      -40°C to +85°C
